MVE 103 BASIC
MVE 103 - BASIC (FREEZER ONLY, NO PLUMBING/CONTROLLER)

MVE 103 - BASIC (FREEZER ONLY, NO PLUMBING/CONTROLLER)

Flat Rate Shipping

Call 724-263-6601
8 AM - 10 PM

Great Customer Service

Warranty
In stock

FACTORY WARRANTY

FLAT FEE SHIPPING MAY APPLY

Shipping calculated at checkout.
To see MVE Product prices, hover over or click Add to Cart.

Ask a Question
Specifications

MVE 103 - Basic

Holds up to 9200 1/2 cc straws

The MVE Stock Series provides the ultimate in security for the breeding industry and are primarily used to store semen and embryos. The freezers are designed for pull and pack shipment, with a wide neck opening for easy access. Although engineered for full liquid storage, the MVE Stock Series can be operated in vapor using the available vapor storage accessory packs.
Features

Features include:
• Wide neck opening
• Lowest lift over height
• Largest LN2 capacity

  • Maximum Storage Capacity

       •  1.2 & 2 ml Vials (Internally Threaded): N/A
       •  Quantity of Large Racks 100 cell boxes: N/A
       •  Quantity of Large Racks 25 cell boxes: N/A
       •  Number of Shelves per rack:     N/A
       •  High security Straw Capacity (0.5 ml): 7,728
       •  Number of Canisters (73 mm): 23
       •  Goblets/Canister : Straws/Goblet: 2 : 168
       •  Number of SUC-1 Canisters (2.5" x 2.5" x 11"): 22
       •  Number of 1.2 ml Vials on Canes: 3,168
       •  Number of 2.0 ml Vials on Canes: 1,760
       •  Number of 1/2 cc Straws 10/cane: 6,820

    Performance

       • LN2 Capacity w/o Inventory:39 liters est.
       • LN2 Capacity at Platform Vapor: N/A

    Unit Dimensions

       • Neck Opening: 16.0" (406mm)
       • Useable Internal Height: 12.0" ( 305 mm)
       • Inner Diameter: 16.0" (406 mm)
       • Overall Height: 16.4" (415mm)
       • Door Width Requirement**: 18" (457 mm)
       • Weight Empty: 48 lbs. (22 kg)
       • Weight Full: 117 lbs. (53 kg)

Literature & Manuals

Visit https://mvebio.com/cryogenic-freezers/mve-stock-series/ for more information

Basic Model - NO CONTROLLER

TWO Year Parts Warranty • Five Year Vacuum Warranty

Conforms to MDD 93/42/EEC, the Medical Device Directive for the EU. Freezer systems UL/C-UL Listed.

Additional discounts may be available...Contact us via email to discuss.

You can purchase the freezer on line and we will bill the shipping separately after purchase or email us your shipping address and we can create an invoice for you.
